16 Channel Data Acquisition Board
The 16 Channel Data Acquisition Board is used for sensor data acquisition purpose. The board samples up to 16 channels of data
from various sensors. The signals are conditioned, sampled and then sent to the FPGA which does packetisation of data. The
data is then sent over Ethernet to host system.
The board is used for signal capturing and data processing in naval applications. The board is a Shop Replaceable Unit (SRU) for
Own Noise Analyser Hermetically Sealed Unit (ONA-HSU).
- 16 ADC channels
- 16 signal conditioning channels: multi stage filter
- Automatic gain control
- Manual gain control
- ADCs sampling at 144 ksps with 24-bit width
- Voltage monitoring and reset generation unit
- Two different groups of signal conditioning channels
- Health monitoring function at board level
- Field upgrade support
